M177 Intake Manifolds
Purchase M177 Intake Manifolds
  • SKU: 01-177-02224-6

    M177 Intake Manifolds

  • $3,499.00 $3,499.00

  • Prop 65 warning
    Warning

    This product can expose you to chemicals including carbon black, silica - crystalline, formaldehyde, and lead which are known to the State of California to cause cancer, and lead, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Manufacturer Weistec
Street legal in all the US States No
Engine Family M177
year make model trim engine
2023 Mercedes-Benz C63 AMG S Cabriolet (A205) Twin Turbo 4L V8 (M177)
2022 Mercedes-Benz C63 AMG S Cabriolet (A205) Twin Turbo 4L V8 (M177)
2021 Mercedes-Benz C63 AMG S Cabriolet (A205) Twin Turbo 4L V8 (M177)
2020 Mercedes-Benz C63 AMG S Cabriolet (A205) Twin Turbo 4L V8 (M177)
2019 Mercedes-Benz C63 AMG S Cabriolet (A205) Twin Turbo 4L V8 (M177)
2018 Mercedes-Benz C63 AMG S Cabriolet (A205) Twin Turbo 4L V8 (M177)
See more

Product Description



The Weistec M177 Intake Manifolds feature a cast aluminum construction for increased strength, when compared to OEM plastic manifolds. Engineered and designed with increased plenum volume to support better flow and significantly higher power levels. The manifolds install directly in place of the OEM plastic manifolds making them ideal replacements for broken OEM manifolds, as well as a supporting upgrade for those looking to maximize the horsepower of their vehicle. Our manifolds are manufactured to allow port injection to meet the high fuel demands of large turbos and high ethanol content fuels. For those that do not want to run port injection, the manifolds include plugs and brackets to seal off the injector ports. Each manifold also has a 1/8" NPT port that can be used as boost/vacuum reference points while also retaining all ports for OEM sensors and emissions connections.

Mercedes M177 Intake Manifold with Non-Port Injection

Non-port Injection

Includes:
  • Intake manifolds

  • Port injection block off plugs and brackets

  • Mounting hardware

NOTE: Port injection fuel rails, lines, injectors, and controller are NOT INCLUDED


Optional Port Injection

For those customers that are looking to add Port Injection to the Weistec Intake Manifolds, we offer a complete set of fuel rails, brackets, fittings, and push-lock fuel lines designed specifically to fit perfectly to the manifolds. With this kit, you will be able to install injectors of your choice along with a port injection controller to greatly increase fuel system capacity. Fuel rails are machined from extruded -8 billet aluminum and all fuel line connections are -8 AN fittings to ensure correct sealing.

Includes:

  • Weistec -8 Billet Fuel Rails

  • Fuel Rail Brackets

  • 8 Push Lock Fittings and Line

  • Fuel Feed Line adapter

  • Misc. Hardware


NOTE: Fuel injectors and port injection controllers are NOT INCLUDED. Expert install required

Mercedes M177 Intake Manifold with Port Injection
